ASNTO XT M bottle blowing machine |SNTO| bottle blowing machine,pet bottle blowing
| Model No. ?XT2500M | 1 |
| number of cavity? | 1 |
| clamping stroke? | 160 mm |
| production? | 900pcs/hr |
| total power? | 31 kw |
| actual power consumption? | ≤11 kw |
| pressure for working? | 10 kg |
| pressure for blowing? | 30 kg |
| flow rate for working? | 1.0 m3 |
| flow rate for blowing? | 1.2 m3 |
| neck diameter? | 24-120 mm |
| max diameter? | 150 mm |
| max height? | 320 mm |
| machine size LxWxH? | 2.1x1.75x2.1 m |
| machine weight? | 1450 kg |
| Model No. ?XT5500M | 1 |
| number of cavity? | 1 |
| clamping stroke? | 200 mm |
| production? | 650pcs/hr |
| total power? | 38 kw |
| actual power consumption? | ≤15 kw |
| pressure for working? | 10 kg |
| pressure for blowing | 30 kg |
| flow rate for working | 1.8 m3 |
| flow rate for blowing? | 2.2 m3 |
| neck diameter | 24-120 mm |
| max diameter? | 180 mm |
| max height? | 320 mm |
| machine size LxWxH? | 2.58x1.65x2 m |
| machine weight? | 1850 kg |
| Model No. ?XT20L | 1 |
| number of cavity? | 1 |
| clamping stroke? | 320 mm |
| production? | 300pcs/hr |
| total power? | 50 kw |
| actual power consumption? | ≤20 kw |
| pressure for working? | 10 kg |
| pressure for blowing? | 30 kg |
| flow rate for working? | 2.5 m3 |
| flow rate for blowing? | 3.5 m3 |
| neck diameter? | 38-80 mm |
| max diameter? | 300 mm |
| max height? | 500 mm |
| machine weight? | 3500 kg |
